ThermoFlex®XTRA
fabrics
Nylon, Leather, and other Heat-Sensitive Fabrics
sizing
Available Widths (in.):
15” and 20”
Available Lengths (ft.):
15’, 30’, 45’, 60’ and 90’, rolls
thickness
4.5 mils/112 microns
• Great for heat-sensitive materials like nylon and leather
• Most colors are layerable (exceptions see below)
• Smooth, matte finish
• Soft to the touch
Do you love ThermoFlex® Plus but wish you could apply it to nylon, leather, rayon, and other heat-sensitive materials? ThermoFlex® Xtra is the perfect product for you! It has a soft hand and strong grip with a quick press.
ThermoFlex® Xtra has incorporated the best features of ThermoFlex® Plus- easy handling, cutting and weeding but with a thicker polyester carrier sheet and a low-tack carrier adhesive. This enables easy weeding without lifting the cut image from the carrier!
LASER compatible
Application Instructions
IT'S BEST TO TEST!
45° Blade
Cut this material into a mirror image.
300°-305° F
Medium Pressure
Pre-press garment for 5 seconds, then press the design for 3-5 seconds.
Peel cold, then cover with a PTFE sheet and re-press for 10 seconds.
Follow wash instructions for Nylon. Turn inside-out, cold water, and tumble dry low. Suitable for dry-cleaning.
Yes with the following exceptions- Columbia Blue, Old Gold, and Antique Silver are top layer only
ThermoFlex® Xtra will also adhere to some silicon-coated materials with sufficient surface texture to permit the adhesive to grip when transferred according to directions.
Columbia Blue, Antique Silver and Old Gold will not layer. These colors cannot have layers adhered on top of them, although we have successfully layered these products on top of other colors.
Use settings for ThermoFlex PLUS for application to polyesters.
Please be advised that dye migration has occurred with low energy dyes in polyester and poly-blend fabrics.
Tech Info
Tech PDF includes product thickness, roll sizing, and other technical information
If you’re using this product for the first time or trying a new garment, it’s always best to test on an inconspicuous area or spare garment before applying final production.
Cut Settings
PLEASE NOTE: Every blade and machine is a little bit different- always remember to test cut! These cut settings are a starting point to be adjusted to your blade and machine.
Cricut
- Material: Vinyl
- Pressure: Default
- Blade: Fine-Point Blade
Silhouette
- Material: Heat Transfer, Smooth
- Blade: 3
- Speed: 8
- Force: 6
Graphtec
- Speed: 8
- Force: 14
We use a 45° blade.
Product Colors
Mouse over the swatches for product name and number!
White
TFX-8100
Storm Grey
TFX-8150
Black
TFX-8236
Red
TFX-8301
Orange
TFX-8333
Maroon
TFX-8350
Athletic Gold
TFX-8426
Navy Blue
TFX-8513
Royal Blue
TFX-8522
Columbia Blue
TFX-8576
Royal Purple
TFX-8584
Kelly Green
TFX-8633
Forest Green
TFX-8676
Antique Silver
TFX-8834
Old Gold
TFX-8843
Color Palette Download
Includes palettes for EconomyFlex, Subliblock, Subliblock Turbo, ThermoFlex Light, ThermoFlex Plus, ThermoSport, ThermoFlex Turbo, ThermoFlex Turbo Brights, and ThermoFlex Xtra.
