fabrics
sizing
Available Widths (in.):
19.5” only
Available Lengths (ft.):
10’, 20’, and 30’ rolls
thickness
24 mils/600 microns
• Extremely thick HTV
• Adds extra importance to your designs and logos
• Excellent bottom layer
Add depth to your designs with Dimension™!
Dimension™ is a very thick material. This thickness gives your designs a very 3D feel. It is available in White & Black. Are you looking for more colors? Check out Dimension™ 2!
LASER compatible
Application Instructions
IT'S BEST TO TEST!
If you’re using this product for the first time or trying a new garment, it’s always best to test on an inconspicuous area or spare garment before applying final production.
60° Blade Recommended, with high pressure – may need to cut twice.
Cut this material into a mirror image.
320° F
Medium Pressure
25 seconds
Peel cold.
Wash inside out, warm water, and hang to dry. NOT suitable for dry-cleaning or tumble drying.
Yes
Tech Info
Tech PDF includes product thickness, roll sizing, and other technical information
Cut Settings
PLEASE NOTE: Every blade and machine is a little bit different- always remember to test cut! These cut settings are a starting point to be adjusted to your blade and machine.
Cricut
- Feed material in without cutting mat
- Material: Light Cardstock
- Pressure: Default
- Blade: Fine-Point Blade
Silhouette
- Material: Heat Transfer, Flock
- Blade: 4
- Speed: 8
- Force: 33
Graphtec
- Make sure the blade is extended out far enough to cut through material
- Speed: 8
- Force: 30
We use a 60° blade.
Special Precautions: Will NOT stretch. We do not recommend cutting fine-detailed designs with this product.
Product Colors
Mouse over the swatches for product name and number!
White
DIM-001
Black
DIM-002
