SUBLIBLOCK®TURBO – Specialty Materials

fabrics

Cotton, Uncoated Polyester, Fabric Blends, Cotton/Polyester Blends, Polyester/Acrylic Blends

Excluding Nylon

sizing

Available Widths (in.):
15” and 20”

Available Lengths (ft.):
15’, 30’, 45’, 60’, 75′ and 90’ rolls

thickness

5.2 mils/130 microns

• Goes on at low temperatures and quick press to prevent press marks on the garment
• Reformulated Subliblock® for modern performance polyesters
• Blocks dye migration
• Extremely opaque

Are you having problems with dye migration? Then Subliblock® Turbo is your solution!

Many of today’s imported polyester fabrics are colored with inexpensive low energy dyes. These dyes migrate quickly into pressed materials with minimal heat. They can also bleed into pressed materials slowly over time at normal room temperature!

Subliblock® Turbo blocks dye migration to stop that issue in its tracks. It is essentially Subliblock® that has been reformulated for modern performance polyesters. This HTV’s low-temperature setting prevents heat-press marks on polyester garments.

It has a soft hand, excellent opacity, and blocks dye-migration. It has a pressure-sensitive carrier that enables easy weeding and re-positioning.

LASER compatible

Application Instructions

IT'S BEST TO TEST!

If you’re using this product for the first time or trying a new garment, it’s always best to test on an inconspicuous area or spare garment before applying final production.

CUTTING
45° Blade

MIRRORING
Cut this material into a mirror image.

TEMPERATURE
270° F

PRESSING
Medium Pressure

TIMING
5 seconds

PEELING
Peel warm.

WASHING
Wash inside-out, with warm water and tumble dry normal. Suitable for dry-cleaning.

LAYERABLE?
Yes with the following exceptions- neon colors and metallics are top layer only

Do not pre-heat the garment. Do not roll this material up in the opposite direction that it came- it will lead to delamination lines. After cutting your design, do not leave hanging on the cutter. If bubbling around the cut lines appears- lay it out flat and smooth down the bubbles with your hand.

Tech Info

Tech PDF includes product thickness, roll sizing, and other technical information

Cut Settings

PLEASE NOTE: Every blade and machine is a little bit different- always remember to test cut! These cut settings are a starting point to be adjusted to your blade and machine.

Cricut

Material: Light Cardstock
Pressure: Default
Blade: Fine-Point Blade

Silhouette

Material: Heat Transfer, Smooth
Blade: 3
Speed: 8
Force: 9

Graphtec

Speed: 8
Force: 16

We use a 45° blade.

Product Colors

Mouse over the swatches for product name and number!

White

SB-3105-T

Red

SB-3301-T

Orange

SB-3333-T

Athletic Yellow

SB-3426-T

Columbia Blue

SB-3576-T

Antique Silver

SB-3834-T

Old Gold

SB-3843-T

Neon Pink

SB-3910-T

Neon Yellow

SB-3920-T

Neon Orange

SB-3930-T

Neon Green

SB-3940-T

Color Palette Download

Includes palettes for EconomyFlex, Subliblock, Subliblock Turbo, ThermoFlex Light, ThermoFlex Plus, ThermoFlex Sport, ThermoFlex Turbo, and ThermoFlex Xtra.
