sizing
Available Widths (in.):
19.5” only
Available Lengths (ft.):
10’, 20’, and 30’ rolls
thickness
Varies per color:
29.5 mils/750 microns +/- 10%
• Extremely thick HTV
• Adds extra importance to your designs and logos
• Wide variety of colors
Make your designs stand out with Dimension™ 2!
Dimension™ 2 is similar to the original Dimension™, but includes neon and metallic colors. Dimension™ 2 is very thick. This thickness adds a 3D look and feel to your designs. Are you ready to take your designs to the next dimension?
LASER compatible
Application Instructions
IT'S BEST TO TEST!
If you’re using this product for the first time or trying a new garment, it’s always best to test on an inconspicuous area or spare garment before applying final production.
60° with high pressure *may need to cut twice
Cut this material into a mirror image.
300° F
Medium Pressure
5 seconds
Warm then turn garment inside-out and re-press for 20 seconds.
Wash inside-out, warm water, hang to dry. NOT suitable for dry-cleaning or tumble drying.
Top layer only
Special Precautions: We do not recommend cutting fine details with this product.
Tech Info
Tech PDF includes product thickness, roll sizing, and other technical information
Cut Settings
PLEASE NOTE: Every blade and machine is a little bit different- always remember to test cut! These cut settings are a starting point to be adjusted to your blade and machine.
Cricut
- Feed material in without cutting mat
- Material: Light Cardstock
- Pressure: Default
- Blade: Fine-Point Blade
Silhouette
- Material: Heat Transfer, Flock
- Blade: 4
- Speed: 8
- Force: 33
Graphtec
- Make sure the blade is extended out far enough to cut through material
- Speed: 8
- Force: 30
We use a 60° blade.
Product Colors
Mouse over the swatches for product name and number!
White
DIM2-201
Black
DIM2-202
Old Gold
DIM2-203
Athletic Gold
DIM2-204
Antique Silver
DIM2-205
Royal Blue
DIM2-206
Red
DIM2-208
Neon Pink
DIM2-210
Green
DIM2-214
Neon Yellow
DIM2-220
Neon Green
DIM2-240
